3.382,80 TL
Technical Details:
-Up to Ø 16 pcd width 2.5mm and two channel body type,
It can be sharpened 3-4 times.
-From Ø 16 onwards, pcd width is 3.5mm and three-channel body type,
Can be sharpened 7-9 times.
-Inch based such as Ø 3/8, 1/2, 5/8, 3/4 mm
production can be done.
-Axial angle varies with diameter.
Technical Detail:
-Pcd width 2.5mm up to Ø 16 and two flutes body type,
Can be sharpened 3-4 times.
-Pcd width 3.5mm from Ø 16 and three flutes body type,
Can be sharpened 7-9 times.
-Can be produced in inch base such as Ø 3/8, 1/2, 5/8, 3/4mm.
-The axial angle of these tools changes with the diameter.
APPLICATION:
-Paper, plastic coated or uncoated plywood, MDF, HDF
and is ideal for high-quality chipboard panels.
-For CNC router.
-If possible, instead of cutting vertically, cutting with a ramp will extend the life of the tool.
Application:
-Paper, plastic coated or uncoated plywood, MDF, HDF
and is ideal for high quality chipboard panels.
-For CNC router.
-If possible, cutting with a ramp instead of a vertical dive increases tool life.
*For tools with a shank diameter of 25, the total length is produced 5 mm longer.
*For tools with a shank diameter of 25, the total length is produced 5 mm longer.
| CODE | D | L | LT | Z | H | d |
| 6000-500 | 10 | 22 | 75 | 3+1HM | 2.5 | 10-12 |
| 6000-501 | 12 | 25 | 75 | 4+1HM | 2.5 | 12-20 |
| 6000-502 | 12 | 36 | 85 | 4+1HM | 2.5 | 12-20 |
| 6000-503 | 16 | 25 | 85 | 4+1HM | 3.5 | 16-20 |
| 6000-504 | 16 | 36 | 95 | 4+1HM | 3.5 | 16-20 |
| 6000-505 | 18 | 25 | 85 | 4+1HM | 3.5 | 18-20 |
| 6000-506 | 18 | 36 | 95 | 4+1HM | 3.5 | 18-20 |
| 6000-507 | 18 | 44 | 105 | 5+1HM | 3.5 | 18-20 |
| 6000-508 | 20 | 25 | 85 | 4+1HM | 3.5 | 20-25 |
| 6000-509 | 20 | 36 | 95 | 4+1HM | 3.5 | 20-25 |
| 6000-510 | 20 | 44 | 105 | 5+1HM | 3.5 | 20-25 |
| 6000-511 | 20 | 55 | 115 | 6+1HM | 3.5 | 20-25 |
| 6000-512 | 20 | 65 | 125 | 7+1HM | 3.5 | 20-25 |
* If you request a different size, please consult by specifying the brand and model of your machine. * If you request a different size, please consult by specifying the brand and model of your machine.
